Panel Mount Female 3.5 Audio Jack to Cable male 3.5 Audio Jack Connector

Product Overview – Panel Mount Female 3.5 Audio Jack to Cable male 3.5 Audio Jack Connector

Our panel mount 3.5mm female audio jack connector is engineered for B2B clients seeking robust and versatile audio interface solutions. Designed with a threaded mounting system and high-quality materials, this connector ensures secure installation and stable audio signal transmission in demanding environments. It is ideal for extending or relocating audio ports in professional setups such as industrial control panels, automotive audio systems, public kiosks, and custom audio equipment. The product is available in multiple configurations, including solder-type terminals and short cable extensions, to accommodate diverse project requirements

Key Features

• Rugged Construction: Zinc alloy or reinforced plastic housing with corrosion-resistant plating (e.g., gold or nickel) for long-term durability in harsh conditions.
• Easy Panel Installation: Threaded design with locking nuts (e.g., M22×1 thread) for simple mounting into standard panel holes (e.g., φ22.5mm–24mm). Supports panel thicknesses up to 13mm.
• Secure Connection: 3-pole TRS (Tip-Ring-Sleeve) stereo configuration ensures clear left/right channel and ground separation, minimizing signal loss.
• Broad Compatibility: Works with all standard 3.5mm audio devices (e.g., headphones, microphones, speakers) and integrates seamlessly with PC sound cards, car stereos, and DIY audio projects.
• B2B-Focused: Available in bulk packs (e.g., 5–10 units) with OEM customization options for connector types, cable lengths, and housing materials.

Technical Specifications Table

Applications

• Industrial Audio Systems: Integrate into control panels for audio monitoring, alarms, or intercoms in manufacturing facilities.
• Automotive & Marine: Dashboards or console installations for car stereos, marine audio systems, and USB/AUX combo ports (e.g., JL Audio-style setups).
• Public Kiosks & Displays: Provide user-accessible audio ports for information kiosks, ticketing machines, or digital signage.
• DIY Audio Projects: Custom amplifier boxes, home theater setups, and repair solutions for headphones or speakers.
• Professional AV Equipment: Rack-mounted audio interfaces, mixers, and microphone panels for studios or event venues.

Installation Guide

1. Panel Preparation: Drill a clean hole (22–24mm diameter) in the panel surface.
2. Mount Connector: Insert the jack from the front, secure it with the included locking nut from the rear, and tighten to prevent loosening.
3. Wiring: For solder-type models, connect wires to the labeled terminals (left channel, right channel, ground). Pre-wired versions plug directly into devices.
4. Testing: Verify audio clarity and channel balance with a test device to ensure proper signal transmission.

Quality Assurance

As a factory-direct supplier, we subject all connectors to rigorous testing, including insertion durability (>10,000 cycles) and impedance stability. Custom OEM orders welcome, with support for technical drawings and sample approvals.
